It is the latest innovative and advanced road cleaning vehicles with the function of sweeping and suction. It is mainly suitable for mechanization cleaning operations in urban roads, highway, airport. The truck has the advantages of high working efficiency, advanced and reliable technology, well-designed appearance, applied for multiple patents and the technology is in the domestic leading position.
|
Auxiliary Engine Model |
ISUZU 4JB1-TCH |
|
Sweeping Width (m) approx. |
3 |
|
Dustbin Volume (m³) |
4.2 |
|
Water Box Volume(m³) |
1.2 |
Type of cleaning device: center-mounted four-disc sweep + rear-mounted nozzle, the disc can automatically avoid obstacles;
The nozzle adopts a rolling-type enhanced nozzle, which has a built-in rolling sweep to prevent leakage of garbage; a rolling rubber wheel with three-point floating support and a strong road contouring function, which can adapt to the cleaning requirements of different road surfaces, is a domestic initiative; optional Equipped with a new type of leaf sweep nozzle with national patent technology protection；
It has a drainage and leakage prevention device, which can effectively prevent the accumulation of dirt, prevent secondary pollution caused by dirt falling back to the ground and blocking the garbage straw;
The dustbin is made of SUS304 single-layer whole stainless steel material, with high structural strength and no rust;
with enhanced dust pressure function device, can adapt to the cleaning of thick dirt road；
with a variety of safety alarm devices: low water level in the clear water tank, operation prompts, auxiliary engine water temperature, oil pressure, back-up prompts, hydraulic oil leakage alarms, dump box dumping, resetting and rear door opening and closing safety alarms and other devices；
The auxiliary engine and fan adopt a centrifugal clutch connection device, which can ensure that the auxiliary engine is automatically disconnected from the fan when the auxiliary engine is started at no load and the auxiliary engine is stopped；
using intelligent control system, electric and hydraulic centralized control, simple operation, the driver can complete various operations in the cab.
