This model is equipped with two garbage tanks and a hazardous waste container, which can collect and transport multiple types of waste at the same time, realizing “one vehicle with multiple uses” and effectively improving the collection and transportation efficiency of various types of waste.
|
Parameters |
FLM5180ZFJDF6 |
|
Chassis Model |
DFH1180EX8 |
|
Emission Standard |
China VI |
|
Top Speed (km/h) |
89 |
|
Front Garbage Tank Volume (m3) |
3.3 |
|
Rear Garbage Tank Volume (m3) |
7.2 |
|
Hazardous Garbage Tank Volume (L) |
115 |
|
Sewage Tank Volume (L) |
710 |
|
Rear GarbageTankCompression Method |
Bidirectional |
|
Front Garbage Tank Lifter Cycle Time (s) |
≤l 6 |
|
Rear Garbage Tank Lifter Cycle Time (s) |
≤11 |
|
Dimension (LxWxH) (mm) |
8905x2500x3010 |
The truck is equipped with multiple garbage tanks, which can realize the combined collection and transportation of household garbage, other garbage, dry garbage, recyclable garbage, and hazardous garbage to meet the needs of garbage classification.
The front dustbin operation adopts the form of loading on the right side and unloading on the left side. The weight of the truck is evenly loaded on the left and right, the unloading center of gravity is low, and the risk of eccentric loading is small.
The front tank is sealed with a top folding cover to ensure no garbage leakage during transportation and prevent secondary pollution.
The discharge port of the front tank is equipped with a diversion device, which is convenient for guiding the discharge and keeping the whole vehicle clean.
The operating system of the front compartment is equipped with a fixed control box on the left and right sides and two control modules of wireless remote control, which increase the flexibility of operation. The operation of the fixed control box is convenient for personnel to observe the loading and unloading of the vehicle.
The cab is designed with a warning light for the tank not in place to remind the driver that the tank is not returning to improve the safety of the operation.
The U-shaped integrally formed truss trough with Japanese technology and high strength is used as the movable guide rail of the garbage ejector for the rear tank.
