All Weather Washing & Sweeping Truck – FLM5180TXSDF6Q

Innovatively developed by Fulongma, a new product that can be used for all-weather cleaning operations. The utility model is suitable for the area cleaning operation where the winter temperature is above -10 ℃ and solves the problem that the road surface freezes after the operation when the temperature is lower than zero in the north of the traditional cleaning sweeper truck in winter. The four-in-one operation mode of “washing, sweeping, suction and drying”. Integrated control and display integrated LCD screen in the cab to realize one-button intelligent operation.


Main Parameters

Auxiliary Engine Model

Cummins QSB5.9-C160-30

Sweeping Width (m) approx.


Dustbin Volume (m³)


Water Box Volume (m³)


High Pressure Water Pump Pressure(Mpa)


Drying drum power (Kw)

≥70 (× 2 pieces)

Drying coverage width (m)



All-weather operation is possible: temperature -10 ° C to 40 ° C can be washed. Effectively solve the problem of freezing and wet road surface caused by water spraying in cleaning operations when the winter temperature is below zero.

The working device adopts the original layout of “central two-disk scanning + central two-side suction + central double suction mouth wide suction nozzle”. It has a multi-functional operation mode to achieve road cleaning, cleaning, washing and dust suction.

Automatically heats when the ambient temperature is lower than the set value, to prevent pipeline components from freezing and cracking when they are transferred, operated, or parked in a low temperature environment.

Using the original suction nozzle structure, wide coverage and strong suction, to ensure that the road surface garbage and sewage are absorbed within the maximum range of the operation range, so that the road surface is clean and dry.

The original drying technology, and the special drying system for washing and sweeping vehicles perform the combined operation of blowing, drying and rolling on the road surface after washing and sweeping. With hydraulic lifting and left and right telescopic system, it can achieve low-ground drying and can extend the drying range to 3.5m.

One-click pneumatic net pipe technology, after the operation is completed, only need to open the pneumatic net pipe switch in the cab, it can automatically complete the drainage of residual water in the waterway system, effectively ensuring that the water spray device parts are not caused by Freeze cracking causes structural damage.

Core operation device heating and heat preservation technology.

The vehicle is equipped with 2 sets of side spray cleaning systems. In winter, the thermal insulation side spray cleaning system is turned on, and in summer, the common side spray cleaning system is switched. Improve the reliability of the whole vehicle and greatly increase the life of the special operation device.

Efficient and energy-saving cleaning technology, using high pressure and low flow type waterway system, cleaning pressure can reach 13Mpa, sustainable operation time is greatly extended.

The advanced electronic liquid level display system can be used to monitor the tank liquid level in real time in the cab.

With hydraulic buffer type sweeping ground distance automatic adjustment technology, the contact force between the sweeping brush and the ground is kept at a fixed value, and the contact surface between the sweeping brush and the ground remains unchanged. After the sweeping brush is worn, it can be automatically compensated without manual adjustment. Ensure that the cleaning efficiency is not affected.

The waste bin adopts double oil cylinders for self-unloading and unloading. At the same time, there are high-pressure nozzles in the box, which can quickly rinse the waste bin.

The shape of the whole car box is made of SUS304 stainless steel, with a folded bar structure, the box body is evenly stressed, the structural performance is strong, and the appearance is beautiful.

Equipped with multi-angle shoulder cleaning nozzles, it can adapt to a variety of shoulder heights and effectively remove garbage from dead ends of shoulders.

It has various safety alarm devices: low water level of clear water tank, high water level of sewage and garbage bin, hydraulic oil leakage, operation reminder, water temperature of auxiliary engine, oil pressure, reminder of reversing, etc.

Adopt CAN bus intelligent control system to realize intelligent centralized control of electricity, liquid and gas. The driver can complete various actions in the cab through the display screen and understand the vehicle operating conditions, operating parameters and fault information.

The left and right sweeping discs and the left and right suction have obstacle avoidance protection and reset functions.

The central suction nozzle has a hydraulic floating function, which effectively extends the life of the rubber roller.
