The truck is small in appearance and flexible in driving. It is mainly used for household garbage collection in residential quarters and small streets and peel compartment garbage collection, and for short-distance transportation. It has outstanding advantages such as strong applicability and less pollution.
|
Parameters |
FLM5030ZLJFS6 |
|
Chassis Model |
BJ1032V4AV5-01 |
|
Emission Standard |
China VI |
|
Engine Model/Power (kW) |
DAM16KL/90 |
|
GVW(kg) |
3495 |
|
Garbage Tank Volume (m3) |
Type-A: 3.5, Type B:4.5 |
|
Garbage Tank Dumping Angle ( ° ) |
≥45 |
|
Sewage Tank Volume (L) |
20 |
|
Dimension (L×W×H) (mm) |
5135×1740×2005 |
The truck is flexible and convenient to turn, with a small turning radius and good maneuverability. It has low fuel consumption and low noise, making it suitable for urban operations.
The truck body adopts high-strength rust-resistant materials to ensure the overall structural strength and rigidity.
This product pays attention to the safety of use, and the warning light is specially designed to ensure the safety of personnel.
The optimized design of the operating system can be completed in the cab.
The structure is simple, and the hydraulic power unit is adopted. Using integrated electronic control and hydraulic components, the system is highly integrated, durable and reliable.
The truck is equipped with a control panel in the cab, and the operator can directly control the operation from the seat and manipulate the dumping of the garbage tank.
