This truck is the latest environmental monitoring vehicle developed by FULONGMA. It is used for the automatic collection, processing, and storage of regional environmental data and observes the dust information of the current environment in real-time.
|
Parameters |
FLM5030XJEFP6 |
|
Chassis Model |
BJ1037V3MV6-6L |
|
Emission Standard |
China VI |
|
Chassis Engine Model/Power (kW) |
4G20TI5/175 |
|
Top Speed (km/h) |
175 |
|
Concentration Range (ug/m3) |
0-1000 |
|
Raised Dust Sensor Ability (ug/m3) |
≤0.3 |
|
Working Environment |
-30 to +60℃, 10-95%RH, No Condensation |
|
Trunk Volume (m3) |
≥2.25 |
|
Dimension (LxWxH)(mm) |
5630x1940x2100 |
An on-board LED display is installed in the cab, which can display real-time environmental observation data.
The truck has functions such as automatic recording, over-limit alarm, and data communication, which can realize automatic collection, processing, and storage of regional environmental data. With strong scalability, the system program adopts a modular structure to facilitate the access of various sensors. The data collector uses a high-performance microprocessor as the main control CPU, and has a large built-in capacity memory.
Its anti-shock structure conforms to the industrial control standard design and is suitable for use in harsh industries or environments. The vehicle has a power failure protection function and the stored data will not be lost due to power failure.
The roof monitoring system adopts a waterproof design with the IP65 protection level. Each sensor has advantages such as fast response, high measurement accuracy, large storage capacity, stable performance, and can work in harsh environments for a long time. The roof LED display can provide information on the current dust status in real-time.
