This truck adopts the principle of negative pressure suction and one-way air intake (no back-blowing airflow), making it possible to collect dust only, preventing dust from leakage, and has no zero PM2.5 emission. With wet and dry mode, the vacuum sweeper truck can operate in all-weather environments. It is suitable for mechanized cleaning operations of cement concrete pavements and asphalt pavements such as urban roads, viaducts, squares, airports, docks, factories, etc.
|
Main Parameters |
FLM5180TXCYJBEV |
|
Chassis Model |
CA1180P62L3BEV |
|
Chassis Motor Model/Power (kW) |
TZ370XS-LKM1101/80 |
|
Chassis Battery Capacity (kWh) |
327.82 |
|
Chassis Battery Type/Manufacturer |
Lithium Iron Phosphate Battery/CATL |
|
Superstructure Motor Model/Power (kW) |
WR510-01039/60 |
|
Top Speed (km/h) |
90 |
|
Travel Range (km) |
480 |
|
Maximum Sweeping Width (m) |
3.4 |
|
Sweeping Speed (km/h) |
3.5-25 |
|
Maximum Sweeping Efficiency (m2/h) |
85000 |
|
Stainless Steel Garbage Tank Volume (m3) |
8.5 |
|
Stainless Steel Water Tank Volume (m3) |
0.46 (Optional) |
|
Sweeping Rate (%) |
≥99 |
|
Dumping Angle (°) |
≥47 |
|
Charging Time (h) |
≤2 (Fast Charging) |
|
External Size (L*W*H) (mm) |
9220x2545x3310 |
The truck is equipped with a large-capacity drive battery, which makes the truck’s overall weight smaller, load capacity larger, and has lower driving energy consumption.
The unique arrangement of the sweeping vacuum cover and cylinder slider adjustment mechanism + center-mounted wide suction nozzle solves the dust problem of sweeping operations and can sweep away debris along the curb.
The dry-wet switching control mechanism and the suction opening switch adjustment mechanism of the left and right cleaning devices are set up to activate the diversification of operating modes. According to different operation requirements, dry operation mode and wet operation mode can be used respectively, and the opening degree of the left and right suction switches can be adjusted separately in each mode, which has a wide range of applications.
The garbage tank of this truck is made of stainless steel and will never rust and the unique box structure makes the filter cartridge disassembly and maintenance simpler and more convenient. The garbage tank adopts an inclined plate structure, which is convenient for unloading without manual intervention.
The whole truck adopts 16 cone-shaped membrane filter cartridges with a filtering area ≥of 160 square meters, a large filtering area, and a better suction effect. An air pulse filter cartridge dust removal device is also provided, which can greatly improve the dust removal effect of the filter cartridge and effectively reduce the clogging of the filter cartridge from dust. It is also equipped with a large-capacity garbage tank and dust removal bin, which greatly improves operational efficiency.
The electrical system adopts integrated modular CAN bus control. The panel has real-time display and monitoring functions of fault diagnosis, digital test, auxiliary engine speed, water temperature, operating conditions, and other data. The working status is clear at a glance and easy to maintain.
