This truck is equipped with front flushing, front sprinkling, rear sprinkling, left flushing, and right flushing nozzles, which can spray water to cool or clean the road. It is suitable for sprinkling and cleaning operations on urban roads, highways, squares, ports, and docks.
|
Main Parameters |
FLM5180GQXHDBEV |
|
Chassis Model |
BYD1180D8HBEVD1 |
|
Chassis Battery Type |
Lithium Iron Phosphate Battery |
|
Chassis Battery Model |
CB240 |
|
Chassis Battery Capacity (kWh) |
350.08 |
|
Chassis Motor Model/Rated Power (kW) |
TZ370XS-LKM1302/120 |
|
Top Speed (km/h) |
89 |
|
Flushing Width (m) |
≥24 |
|
Sprinkling Width (m) |
≥l 6 |
|
Rear Water Gun Range (m) |
≥50 |
|
Sprinkler Pump Head (m) |
110 |
|
Sprinkler Pump Flow (m3/h) |
50 |
|
Water Tank Volume(m3) |
8.23 |
|
External Size (L*W*H)(mm) |
8050x2520x2700 |
The truck is equipped with a self-priming two-stage centrifugal pump and is driven by its chassis gearbox. It adopts the first low-level flushing mode in China.
The high-pressure water gun located at the rear of the truck is flexible to operate and has a wide range of working angles. It can be used to spray objects of various heights, and it can also remove some dirty spots that are not easy to clean. It also has an auxiliary fire-fighting function. The spray gun can adjust the shape of sprayed water into a column or mist.
Equipped with left and right cylindrical side spraying nozzles, the nozzle can be adjusted by 360° left and right and 360° up and down.
There are two nozzles on the rear bumper, which are used for daily sprinkling to increase humidity and reduce dust.
The water tank is equipped with a low water level sensor alarm system, which can automatically sound when the water level is low.
A variety of components can be optionally installed: such as rear upper and lower sprays, sewer dredging devices, left and right side watering, rear operation indicator lights to achieve multiple uses in one vehicle.
